Professional-Grade Routing Power — Built for the Workshop, Engineered to Last
The ID WR12HQ Electric Router Machine is a 1850W heavy-duty woodworking router engineered for professionals who demand precision, power, and longevity. Operating at 22,000 RPM no-load speed on a 220–240V Type G supply, this Makita-type plunge router accepts collets up to 12.7mm milling cutter diameter, making it the go-to tool for edge profiling, dado cutting, template routing, and decorative inlay work across wood, MDF, and plastics.
| Key Features | Perfect For |
|
|
- 1850W Rated Power Input at 220–240V / 50–60Hz: The WR12HQ delivers a full 1850 watts of rated power, drawing from a standard Type G British 3-pin plug supply. This high-wattage motor sustains consistent torque even under aggressive material removal, preventing stalling when routing hardwoods, dense MDF, or thick plastics — a critical advantage for production workshop environments.
- 22,000 RPM No-Load Speed with 12.7mm Max Cutter Diameter: The spindle reaches 22,000 revolutions per minute under no-load conditions, delivering the high surface speed needed for clean, splinter-free cuts. The machine accepts milling cutters up to 12.7mm in diameter, with included 6.35mm and 9.52mm collets providing immediate versatility across a wide range of standard router bit shanks.
- Precise Pre-Conditioning Depth Control: The integrated depth adjustment mechanism allows operators to pre-set the exact routing depth before plunging, dramatically reducing the risk of over-routing or under-routing. This is especially valuable for repeat production runs, template work, and decorative inlay routing where consistent depth is non-negotiable.
- Double Insulation Safety Construction: Engineered with a double insulation system that ensures complete electrical isolation between the internal motor components and the outer tool casing. This eliminates the risk of electric shock from casing contact, making the WR12HQ safe for prolonged professional use without requiring an additional earth connection.
- Thickened Base Plate and Comprehensive Accessory Kit: The reinforced, thickened base provides a stable, flat reference surface that resists flex and vibration during operation. The machine ships complete with a straight guide, template guide, trimmer guide assembly, retainer base assembly, two wrenches, and an auto-stop carbon brush set — giving professionals everything needed to begin routing straight out of the box. CE and CB conformity certificates confirm the machine has passed both machine-level and comprehensive electrical safety testing.
- Net Weight 6kg — Balanced for Controlled Plunge Routing: At 6 kilograms, the WR12HQ strikes the balance between mass (which aids stability and reduces chatter) and manageability for extended overhead or freehand routing sessions. The robust build quality, combined with the innovative heavy-duty motor technology, is engineered to outlast comparable tools in its class under continuous workshop conditions.
General Purchase & Comparison Queries
Is the ID WR12HQ compatible with standard router bits available in the UAE and GCC markets?
Yes. The WR12HQ ships with two collets — a 6.35mm (1/4") collet and a 9.52mm (3/8") collet — which are the two most common shank sizes for router bits sold across the UAE, GCC, and international markets. This means you can immediately use the vast majority of straight bits, roundover bits, chamfer bits, and profile bits available locally without needing any adapter.
How does the WR12HQ compare to other 1850W routers in its class?
The WR12HQ is a Makita-type plunge router that matches the form factor and collet compatibility of leading professional routers. Its key differentiators are the double insulation safety system, the pre-conditioning depth control for repeatable plunge depth, and the comprehensive accessory kit — including straight guide, template guide, trimmer guide assembly, and auto-stop carbon brush set — which many comparable routers supply as paid extras. It also carries both CE and CB conformity certificates, confirming it has passed independent machine-level and comprehensive electrical safety testing.
What plug type does this router use, and is it suitable for UAE mains supply?
The ID WR12HQ comes fitted with a Type G British 3-pin plug, which is the standard plug type used throughout the UAE, UK, and most GCC countries. It operates on 220–240V at 50/60Hz, which is fully compatible with UAE mains supply (220–240V / 50Hz). No adapter or transformer is required for use in the UAE.
Product-Specific and Usage Queries
What is the maximum router bit size this machine can accept?
The WR12HQ accepts milling cutters up to 12.7mm in diameter. The included collets cover 6.35mm (1/4") and 9.52mm (3/8") shank sizes. For larger-diameter profile bits or panel-raising bits, always verify the bit's shank diameter matches one of the included collets, and ensure the cutter diameter does not exceed the 12.7mm maximum to avoid overloading the spindle bearing.
How does the depth control system work on the WR12HQ?
The WR12HQ features a pre-conditioning depth control mechanism that allows you to set your target routing depth before you begin cutting. You adjust the depth stop to your required measurement, lock it in place, and the plunge mechanism will stop precisely at that depth on every pass. This eliminates guesswork and significantly reduces the risk of over-routing or under-routing, making it ideal for repeat production cuts, dado grooves, and decorative inlay work where consistent depth across multiple pieces is essential.
Can this router be used with a router table?
Yes. The WR12HQ's thickened, reinforced base plate is designed for stability and can be mounted inverted into a compatible router table. When table-mounted, the machine's 1850W motor and 22,000 RPM speed provide ample power for edge profiling, raised panel work, and joinery operations. Ensure the router table's mounting plate matches the base dimensions and that the plunge lock is engaged when operating in table mode.
Problem/Solution-Oriented Queries
The router is leaving burn marks on the wood — what should I do?
Burn marks are typically caused by feeding too slowly, using a dull bit, or taking too deep a cut in a single pass. With the WR12HQ running at 22,000 RPM, the bit speed is high — so feed rate must be matched accordingly. Increase your feed speed slightly, ensure your router bit is sharp and clean, and use the pre-conditioning depth control to take shallower passes (multiple light passes rather than one deep cut). For resinous hardwoods, a dedicated spiral upcut bit will also reduce heat buildup significantly.
The machine stopped mid-operation — what could cause this?
The most common cause of mid-operation stoppage is carbon brush wear. The WR12HQ includes an auto-stop carbon brush set precisely for this reason — when the brushes reach the end of their service life, the auto-stop feature cuts power to protect the motor armature from damage. Simply replace the carbon brush set (included in the box) to restore operation. Other causes can include overloading the motor by taking excessively deep cuts or routing very dense material at too slow a feed rate — allow the machine to cool and reduce cut depth before restarting.
The router bit is slipping in the collet — how do I fix this?
Bit slippage is almost always caused by an incorrectly tightened or worn collet. Use both wrenches included in the kit — one to hold the spindle lock and one to tighten the collet nut — and ensure the bit shank is inserted to the correct depth (at least 3/4 of the collet length). Never insert the bit shank all the way to the bottom of the collet; leave a small gap. If slippage persists after correct tightening, inspect the collet for wear or debris and replace if necessary. Always match the collet size precisely to the bit shank — using a 6.35mm collet for a 6.35mm shank or a 9.52mm collet for a 9.52mm shank.
Machine (1 Pcs), Guide Book (1 Pcs), Auto-Stop Carbon Set (1 Pair), Wrench (2 Pcs), Straight Guide (1 Pcs), Retainer Base Assembly (1 Pcs), Template Guide (1 Pcs), Trimmer Guide Assembly (1 Pcs), Collet [6.35 mm] (1 Pcs), Collet [9.52 mm] (1 Pcs)
