Professional-Grade Cutting Power Built for the Toughest Job Sites
The ID WCS235 9-inch Electric Circular Saw Machine is a 1520W heavy-duty circular saw engineered for professionals who demand precision, power, and durability. Designed in the DeWalt style and compatible with a Type G (British 3-Pin) plug, this 240V circular saw delivers a no-load speed of 4100 RPM with a 235mm max blade diameter, making it the go-to tool for straight and bevel cuts in wood, metal, and plastic across construction, woodworking, and industrial applications.
| Key Features | Perfect For |
|
|
- 1520W Rated Power Input — The high-output motor sustains consistent torque under heavy cutting loads, reducing blade stall and ensuring smooth, uninterrupted cuts through dense hardwood, thick plywood, steel sheet, and plastic profiles without overheating or performance drop-off.
- 235mm Max Blade Diameter & 84mm Cutting Depth — The large 235mm blade capacity combined with an 84mm maximum cutting depth allows this saw to handle full-thickness timber sections, structural lumber, and multi-layer sheet materials in a single pass, dramatically improving workflow efficiency on site.
- 45° Bevel Cutting Capability — The adjustable bevel function allows the blade to tilt up to 45 degrees, enabling precise angled cuts for mitre joints, chamfered edges, and decorative bevelling on furniture, flooring, and cabinetry — all without the need for a separate mitre saw.
- Double Insulation Safety Design — The double-insulated construction ensures that all live electrical components are fully isolated from the outer housing, eliminating the risk of electric shock even in damp or dusty environments, making it a safer choice for outdoor and industrial job sites.
- 4100 RPM No-Load Speed at 220–240V / 50–60Hz — Operating at a rated frequency of 50/60Hz and a voltage range of 220–240V, the saw reaches 4100 RPM under no-load conditions, delivering the blade speed necessary for clean, splinter-free cuts across a wide range of materials and thicknesses.
- Type G Plug & Broad Voltage Compatibility — Supplied with a British 3-Pin Type G plug and rated for 220–240V at 50/60Hz, this saw is ready for immediate use across the UAE, UK, and other markets using the same power standard, with no adaptor required.
This machine carries CE certification (Machine Test) and CB certification (Comprehensive Machine Test), confirming compliance with international electrical safety and performance standards. Each unit ships complete with the machine itself, a guide book, an auto-stop carbon set (1 pair), an auxiliary handle, a wrench, and a fixing plate — everything needed to get started straight out of the box.
General Purchase & Comparison Queries
Is the ID WCS235 a genuine DeWalt circular saw?
The ID WCS235 is a DeWalt-type circular saw — it is designed and built to the same functional standard and form factor as DeWalt models, offering comparable 1520W power output, a 235mm blade diameter, and professional-grade construction. It is sold under the ID brand and represents an excellent value alternative for professionals who need reliable performance without the premium brand price tag.
What plug type does this circular saw use, and is it compatible with UAE sockets?
This saw comes fitted with a Type G British 3-Pin plug and is rated at 220–240V / 50–60Hz, which is fully compatible with standard UAE power outlets. No adaptor is required for use in the UAE, UK, or any other country using the Type G socket standard.
What certifications does this circular saw hold?
The ID WCS235 holds both CE certification (Machine Test) and CB certification (Comprehensive Machine Test). These internationally recognised certifications confirm that the machine meets rigorous electrical safety, electromagnetic compatibility, and performance standards, making it suitable for professional use and compliant with European and international market requirements.
Product-Specific and Usage Queries
What is the maximum cutting depth and bevel angle of the WCS235?
The ID WCS235 offers a maximum cutting depth of 84mm at 90 degrees, making it capable of cutting through full-thickness structural timber and thick sheet materials in a single pass. The bevel cutting function adjusts up to 45 degrees, allowing you to make precise angled cuts for mitre joints, chamfered edges, and decorative bevelling without requiring a separate tool.
What materials can the ID WCS235 cut?
The ID WCS235 is designed to cut a wide range of materials including hardwood, softwood, plywood, MDF, metal sheet, and plastic profiles. With a 235mm blade diameter and 4100 RPM no-load speed, it handles both rip cuts and cross cuts efficiently. The appropriate blade type should be selected based on the material — a fine-tooth blade for wood, and a metal-cutting disc for steel or aluminium.
What accessories and components are included with the machine?
Each ID WCS235 unit ships with the machine (1 pc), a guide book (1 pc), an auto-stop carbon set (1 pair), an auxiliary handle (1 pc), a wrench (1 pc), and a fixing plate (1 pc). This complete kit ensures you have everything required for safe setup and immediate operation straight out of the box.
Problem/Solution-Oriented Queries
The saw blade is not cutting straight — what should I check?
If the blade is drifting during cuts, first verify that the fixing plate and blade are correctly installed and tightened using the included wrench. Check that the bevel angle is set to 0 degrees for straight cuts and that the base plate is flush against the material. Using the auxiliary handle for two-handed control significantly improves cut accuracy. If the issue persists, inspect the blade for warping or dullness and replace if necessary.
The motor seems to be losing power during heavy cuts — what could cause this?
Power loss during heavy cuts is most commonly caused by worn carbon brushes. The ID WCS235 includes an auto-stop carbon set (1 pair) precisely for this maintenance need — the auto-stop feature halts the motor when the brushes reach end-of-life, protecting the motor from damage. Replace the carbon brushes with the included set to restore full 1520W rated power. Also ensure the supply voltage is stable at 220–240V and that the extension cable gauge is adequate for the load.
Is it safe to use this saw in dusty or outdoor environments?
Yes. The double insulation design of the ID WCS235 ensures that all live electrical components are fully isolated from the outer casing, significantly reducing the risk of electric shock in dusty, damp, or outdoor conditions. However, it is still recommended to avoid direct exposure to rain or standing water. Always use the auxiliary handle for secure two-handed grip on uneven surfaces, and ensure the work area is stable and well-lit before beginning any cut.
Machine (1 Pcs), Guide Book (1 Pcs), Auto-Stop Carbon Set (1 Pair), Hex Wrench (1 Pcs), Fixing Plate (1 Pcs)
