Professional Sliding Mitre Saw Built for Accuracy, Power, and Longevity
The ID MS255S Sliding 10" Electric Mitre Saw Machine is a professional-grade sliding mitre saw engineered for tradespeople and serious woodworkers who demand precision crosscuts, bevel cuts, and angled cuts in wood and aluminium. Powered by a robust 1800W motor at 6000 RPM with a 255mm blade diameter, this machine delivers clean, repeatable results on every cut. Supplied with a Type G (British 3-Pin) plug and rated at 220–240V / 50–60Hz, it is ready for use across GCC and European markets straight out of the box.
| Key Features | Perfect For |
|
|
- 1800W High-Performance Motor at 6000 RPM: The MS255S is driven by a powerful 1800-watt motor spinning the blade at a consistent 6000 RPM, delivering the torque and speed needed to slice cleanly through hardwoods, softwoods, MDF, and aluminium profiles without bogging down — even under sustained professional use.
- 255mm Sliding Blade System for Extended Crosscut Width: The 255mm (10") maximum blade diameter combined with a sliding rail mechanism dramatically increases the crosscut capacity compared to a fixed-head mitre saw, allowing you to work with wider boards and panels that would otherwise require multiple passes or a larger machine.
- Left and Right Bevel Cutting for Compound Angle Work: The bevel cutting function operates in both left and right directions, enabling compound angle cuts that are essential for crown moulding, angled joinery, and decorative trim work. This dual-direction bevel eliminates the need to flip workpieces, saving time and improving cut accuracy.
- Double Insulation for Maximum Electrical Safety: Built with double insulation throughout, the MS255S ensures that live electrical components are completely isolated from the outer casing and any surface the operator may contact. This critical safety design removes the risk of electric shock even in the event of internal insulation failure, making it suitable for demanding site conditions.
- Heavy-Duty Construction Engineered to Outlast: The MS255S is built on a heavy-duty platform using industrial-grade materials and components designed to withstand the rigours of daily professional use. At 18 kg net weight, the machine provides the stability and mass needed to absorb vibration and maintain cut accuracy over thousands of cycles.
- Comprehensive Accessory Kit Included: The machine ships complete with a guide book, auto-stop carbon brush set, dust bag, spanner, triangular ruler, workpiece clamp, horizontal clamp, and three support bars — giving you everything needed to set up and begin cutting immediately without additional purchases.
The MS255S carries Double Insulation certification and is supplied with a full accessory kit including the machine unit, guide book, auto-stop carbon brush set (1 pair), dust bag, spanner, triangular ruler, clamp, horizontal clamp, and three support bars — everything required for immediate professional deployment.
General Purchase & Comparison Queries
What makes the MS255S different from a standard fixed-head mitre saw?
The MS255S is a sliding mitre saw, meaning its cutting head travels along a set of rails rather than pivoting from a fixed point. This sliding action significantly increases the maximum crosscut width, allowing you to cut wider boards and panels in a single pass — something a fixed-head mitre saw of the same blade size cannot achieve. Combined with the 255mm blade and 1800W motor, it is a considerably more versatile machine for professional carpentry and joinery work.
Is this mitre saw suitable for cutting aluminium as well as wood?
Yes. The ID MS255S is designed for both wood and aluminium cutting. For aluminium, you will need to fit an appropriate non-ferrous metal cutting blade (not included) and use a suitable cutting lubricant. The machine's 6000 RPM no-load speed and stable heavy-duty platform make it well suited to cutting aluminium profiles, extrusions, and light sections commonly used in construction and fabrication.
Which plug type does this machine use and which countries is it compatible with?
The MS255S is supplied with a Type G plug (British 3-Pin) and is rated at 220–240V / 50–60Hz. This makes it directly compatible with the UAE, Saudi Arabia, Qatar, Bahrain, Kuwait, Oman, the United Kingdom, and other countries using the Type G standard. No adapter is required in these markets — simply plug in and begin work.
Product-Specific and Usage Queries
Can this saw make compound cuts — both mitre and bevel at the same time?
Yes. The MS255S supports compound cutting by combining its adjustable mitre table (for horizontal angle settings) with its left and right bevel function (for vertical angle settings). This allows you to set both a mitre angle and a bevel angle simultaneously, which is essential for cutting crown moulding, angled roof trim, and complex joinery where the cut must be angled in two planes at once.
What is the purpose of the auto-stop carbon brush set included with the machine?
The auto-stop carbon brush set is a safety and maintenance feature built into the motor. Carbon brushes conduct electricity to the motor's rotating armature, and they wear down gradually with use. The auto-stop design means the motor will automatically cut power when the brushes reach the end of their service life, preventing damage to the motor's commutator. A replacement pair is included in the box so you can restore the machine to full operation without downtime when the time comes.
How heavy is the MS255S and can it be moved between job sites?
The MS255S has a net weight of 18 kg. While this is a substantial machine that provides excellent cutting stability, it is designed to be transportable between job sites with appropriate handling. The weight contributes directly to the machine's vibration damping and cut accuracy — a heavier platform means less movement during the cut. We recommend using a dedicated carry bag or trolley for regular site-to-site transport.
Problem/Solution-Oriented Queries
My cuts are not coming out square — what should I check first?
If your cuts are not square, start by verifying the mitre table is set to exactly 0 degrees and that the bevel is also at 0 degrees. Use the included triangular ruler to check the blade is perpendicular to the table surface. Also inspect the fence alignment — if the fence is not perfectly straight and square to the blade path, cuts will be skewed. Finally, ensure the workpiece is held firmly against the fence using the included clamp or horizontal clamp to prevent movement during the cut.
The machine stopped working mid-use — what could be the cause?
An unexpected stop during operation is most commonly caused by the auto-stop carbon brush system activating, which means the carbon brushes have reached the end of their service life and the motor has cut power to protect itself. Fit the replacement auto-stop carbon brush set included in the box to restore operation. Other causes can include a tripped circuit breaker due to overload (allow the motor to cool and reset the breaker), or a loose power connection. If the machine does not restart after these checks, contact your authorised service centre.
There is excessive dust when cutting — how can I manage this?
The MS255S includes a dust bag that captures the majority of sawdust generated during cutting. Ensure the dust bag is correctly attached to the dust port and is not full — a full bag significantly reduces extraction efficiency. For higher-volume work or finer dust particles, you can connect the machine to an external dust extractor via the dust port for improved air quality and a cleaner work environment. Always work in a well-ventilated area and wear appropriate respiratory protection when cutting MDF or treated timber.
Machine (1 Pcs), Guide Book (1 Pcs), Auto-Stop Carbon Set (1 Pair), Dust Bag (1 Pcs), Spanner (1 Pcs), Triangular Ruler (1 Pcs), Clamp (1pcs), Horizontal Clamp (1pcs), Support Bar (3pcs)
