ID CS230N 9" ELECTRIC CIRCULAR SAW MACHINE [G-240V] - 28959
Chat with us
Choose options
ID CS230N 9" Electric Circular Saw Machine is a professional-grade 2300W circular saw built for demanding cutting tasks across wood, metal, and plastic. Engineered with double insulation, constant speed electronics, and a retractable lower guard, this 235mm blade circular saw delivers precision, safety, and durability on every cut, from construction sites to workshop benches. Supplied with a Type G (British 3-Pin) plug and CE certified for peace of mind.
| Key Features | Perfect For |
|---|---|
|
|
Professional Cutting Power — Engineered for Precision, Built to Last
- 2300W Rated Power Input — A high-output motor delivers consistent cutting force through hardwood, softwood, metal sheet, and plastic, maintaining performance even under sustained load without overheating or speed drop.
- Constant Speed Electronics — Advanced electronic speed regulation maintains a steady 4000 r/min no-load speed under varying load conditions, ensuring clean, burr-free cuts and faster overall progress on every material.
- 0°–45° Bevel Cutting with Quick-Lock — The precision bevel adjustment system allows the operator to set exact cutting angles from 0° to 45° using a quick-lock mechanism, enabling mitre joints, chamfered edges, and angled structural cuts with repeatable accuracy.
- 235mm (9") TCT Blade with 60 Teeth — The included Tungsten Carbide Tipped blade features 60 teeth for ultra-smooth, fine-finish cuts. The large blade diameter allows deeper cuts through thick stock, making it suitable for heavy-duty construction and joinery applications.
- Retractable Spring-Loaded Lower Guard — A safety-critical feature that automatically retracts the blade cover during the cut and instantly snaps back into position once the cut is complete, protecting the operator from accidental blade contact at all times.
- Double Insulation Construction — The tool's electrical components are fully isolated from the outer casing, eliminating the risk of electric shock even in the absence of a grounded supply — a key safety standard for professional site use.
- Compact Body at 7.1 kg — Despite its 2300W output, the machine's compact engineering keeps the weight to just 7.1 kg, reducing operator fatigue during extended use and improving maneuverability in tight spaces.
The ID CS230N is CE certified (Machine Test), confirming compliance with European safety and electromagnetic compatibility standards. Each unit ships complete with the machine, a TCT 235mm × 60T blade, auto-stop carbon brush set, spanner, and guide book — everything needed to begin cutting straight out of the box.
General Purchase & Comparison Queries
What makes the ID CS230N different from a standard circular saw?
The ID CS230N stands apart with its 2300W heavy-duty motor, constant speed electronics, and a large 235mm (9") TCT 60-tooth blade — specifications typically found in professional-grade tools. Combined with double insulation, a retractable lower guard, and CE certification, it offers a level of safety and performance that exceeds most consumer-grade circular saws in its class.
Is this circular saw suitable for professional or trade use?
Yes. The ID CS230N is engineered for professional and trade environments. Its 2300W rated power, 4000 r/min no-load speed, and robust double-insulated construction make it well-suited for continuous use on construction sites, joinery workshops, and fabrication settings. The included auto-stop carbon brush set further extends the tool's service life under heavy use.
What plug type does this machine use and which countries is it compatible with?
This machine is supplied with a Type G (British 3-Pin) plug and operates on 220–240V at 50/60Hz, making it compatible with the UAE, UK, and other countries using the same power standard. No adapter is required for use in the GCC region or the United Kingdom.
Product-Specific and Usage Queries
What materials can the ID CS230N cut?
The ID CS230N is designed to cut wood, metal, and plastic. The included 235mm × 60T TCT (Tungsten Carbide Tipped) blade is optimised for fine, smooth cuts in timber and sheet materials. For metal cutting, an appropriate metal-cutting TCT blade (sold separately) should be used to ensure clean results and blade longevity.
How does the bevel cutting function work and what angles are supported?
The bevel cutting system allows the blade to tilt from 0° to 45°, enabling angled cuts for mitre joints, chamfered edges, and inclined structural cuts. A quick-lock mechanism lets you set and secure the desired angle quickly and accurately, without the blade shifting during the cut. This makes it ideal for finish carpentry and precision joinery work.
Can the cutting depth be adjusted on this saw?
Yes. The ID CS230N features an adjustable cutting depth controlled via a quick-lock lever, allowing you to set the blade exposure to match the thickness of your material. This is particularly useful for making shallow grooves, rebates, or ensuring the blade does not cut deeper than required — improving both safety and cut quality.
Problem/Solution-Oriented Queries
The saw seems to slow down under load — is this normal?
No — the ID CS230N is equipped with constant speed electronics specifically designed to maintain a steady cutting speed even under load. If you notice significant speed drop, check that the TCT blade is sharp and correctly fitted, and that you are not forcing the saw faster than the material allows. A worn or incorrect blade is the most common cause of speed loss. The included auto-stop carbon brush set also ensures the motor cuts out safely before brush wear causes damage.
How do I ensure safe operation of the blade guard?
The retractable spring-loaded lower guard is designed to operate automatically — it retracts as the blade enters the material and snaps back immediately when the cut is complete. Never manually hold the guard open or bypass it. Before each use, check that the guard moves freely and returns to the closed position without resistance. If the guard sticks or does not return fully, stop use and inspect for debris or damage before continuing.
What should I do if the blade produces rough or splintered cuts?
Rough or splintered cuts are typically caused by a dull or incorrect blade, cutting too fast, or cutting against the grain without proper support. Ensure you are using the correct TCT blade for your material — the included 235mm × 60T blade is optimised for fine cuts in wood. For cleaner results, use masking tape along the cut line, support the workpiece fully to prevent breakout, and let the saw's constant speed electronics do the work at a steady, controlled feed rate.
Machine (1 Pcs), Guide Book (1 Pcs), Auto-stop Carbon Set (1 Pair), Spanner (1 Pcs), TCT Blade [235mm x 60T] (1 Pcs)
