ID CS185N [7"] ELECTRIC CIRCULAR SAW MACHINE [G-240V] - 28958
Chat with us
Choose options
The ID CS185N 7" Electric Circular Saw Machine is a heavy-duty, double-insulated power tool engineered for precision cutting across wood, metal, and plastic. Delivering 1500W of rated power at 5600 RPM no-load speed, this 185mm circular saw combines a compact design with professional-grade performance, ideal for construction sites, woodworking workshops, and serious DIY applications. Supplied with a Type G (British 3-Pin) plug for direct UAE and GCC compatibility.
| Key Features | Perfect For |
|---|---|
|
|
Professional Cutting Power in a Compact, Site-Ready Package
- 1500W Rated Power Input at 220–240V / 50–60Hz: The robust motor delivers consistent torque across the full cutting range, handling hardwoods, engineered boards, and plastics without bogging down — even during extended continuous use on site.
- 5600 RPM No-Load Speed with Constant Speed Electronics: Advanced electronic speed regulation ensures the 185mm TCT blade maintains its target RPM under varying material resistance, resulting in cleaner cuts, reduced tear-out, and faster overall progress.
- 0°–45° Bevel Cutting with Quick-Lock Depth Adjustment: The precision bevel scale and quick-lock mechanism allow the operator to dial in exact cutting angles for mitre joints, chamfers, and angled profiles — with adjustable cutting depth for controlled, repeatable results across different material thicknesses.
- Double Insulation Safety Construction: Engineered so that no live electrical component can make contact with the external housing, providing a critical secondary layer of protection for operators working in damp or demanding site environments — a standard reflected in its CE (Machine Test) certification.
- Retractable Spring-Loaded Lower Guard: The automatic lower blade guard retracts cleanly during the cut and snaps back instantly upon completion, shielding the operator from accidental blade contact and meeting professional safety standards without interrupting workflow.
- Compact and Lightweight at 4.3 kg: The super-compact body keeps the tool manoeuvrable for overhead cuts, tight spaces, and extended handheld use — without sacrificing the structural rigidity needed for straight, accurate cuts across long runs of material.
The ID CS185N carries CE (Machine Test) certification, confirming compliance with European machinery safety directives. The package includes the circular saw machine, a 185mm x 60T TCT blade pre-fitted for immediate use, an auto-stop carbon brush set for extended motor life, a spanner for blade changes, and a guide book — everything required to begin cutting straight out of the box.
General Purchase & Comparison Queries
What plug type does the ID CS185N come with, and is it compatible in the UAE?
The ID CS185N is supplied with a Type G (British 3-Pin) plug, which is the standard plug type used across the UAE, GCC, and UK. It operates on 220–240V at 50/60Hz, making it fully compatible with standard UAE mains power — no adapter or converter required.
Is this circular saw suitable for professional use or only DIY?
The ID CS185N is built for both professional tradespeople and serious DIY users. Its 1500W motor, constant speed electronics, double insulation safety construction, and CE (Machine Test) certification meet the demands of construction sites, joinery workshops, and high-frequency use — not just occasional home projects.
Does the ID CS185N come ready to use out of the box?
Yes. The package includes a 185mm x 60T TCT blade already sized for the saw, along with a spanner for blade changes, an auto-stop carbon brush set, and a guide book. Simply fit the blade, plug in, and begin cutting — no additional accessories are required to get started.
Product-Specific and Usage Queries
What is the maximum bevel angle and how is it adjusted?
The ID CS185N supports bevel cutting from 0° to 45°, covering the full range needed for chamfers, mitre joints, and angled profiles. Adjustment is made via a quick-lock mechanism on the bevel scale, allowing smooth, precise angle setting without tools — and locking firmly in place before the cut begins.
What materials can the ID CS185N cut?
The saw is designed to cut wood, engineered timber, plastic, and light metal depending on the blade fitted. The included 185mm x 60T TCT (Tungsten Carbide Tipped) blade is optimised for clean cuts in timber and sheet materials. For metal cutting, a dedicated metal-cutting blade of the same diameter would be required.
How does the constant speed feature benefit cutting performance?
The constant speed electronics actively monitor and regulate the blade's RPM, preventing the motor from slowing down when it encounters denser or thicker material. This means the 5600 RPM no-load speed is maintained throughout the cut, producing cleaner edges, less burning, and faster throughput — particularly important when cutting hardwoods or making long rip cuts.
Problem/Solution-Oriented Queries
What happens if the carbon brushes wear out?
The ID CS185N includes an auto-stop carbon brush set in the box. When the brushes reach the end of their service life, the auto-stop function cuts power to the motor automatically — preventing damage to the armature. Replacing the brushes with the included spare set restores full operation, extending the working life of the tool significantly.
Is the saw safe to use if the blade guard is damaged or missing?
No. The spring-loaded retractable lower guard is a critical safety component — it automatically covers the blade immediately after each cut, protecting the operator from accidental contact. Operating the saw without a functioning lower guard is unsafe and not recommended. If the guard is damaged, it should be replaced before further use.
The saw is slowing down mid-cut — what could be causing this?
If the saw slows noticeably during a cut despite the constant speed electronics, the most common causes are a blunt or incorrect blade for the material, cutting at a depth that exceeds the blade's capacity, or worn carbon brushes reducing motor efficiency. Check that the 185mm TCT blade is sharp and appropriate for the material, verify the cutting depth setting, and inspect the carbon brushes — replacing them with the included spare set if worn.
Machine (1 Pcs), Guide Book (1 Pcs), Auto-stop Carbon Set (1 Pair), Spanner (1 Pcs), TCT Blade [185mm X 60T] (1 Pcs)
